F-MAT Underfloor Heat Mat

Welcome To Share This Page

Aluminum Foil Twin Conductor Under Floor Heating Mat 150W/M2

Model: F-MAT

Introduction

F-MAT is designed for use under laminate, under carpet, engineered and most solid wood floors,
having the heating cable pre-spaced onto an Aluminum foil.Very thin and very easy for installation.
Increasing floor level by only 1.2mm.

CONSTRUCTION:

Cable construction Twin condcutor
Conductor Solid heating core
Insulation Fluoroplastic
Thickness 1.2mm
Connector Out splice
Product specification 50mm
Rated voltage 220v
Cable spacing 50mm
Cold lead 2.5m length
Power output 150w/m2
